Description
CAPACITY
| Cooling EER (BTUH / Watt) | 10.6 |
| Cooling BTUH (MIN) | 9800 |
| Cooling BTUH (MAX) | 10000.000000 |
| Dehumidification (pts./hr.) | 2.7/2.7 |
FEATURES
| Louver Style | 6-Way |
| Product Type | Built-In |
| Air Discharge | Over / Under |
| Style | Thru-Wall |
| Chassis Type | Slide-In |
| Connected Capabilities | Amazon Alexa Google Home |
| Filter Type | Rigid Tilt-Out Washable |
| WiFi Connect | Built-In |
| Remote Control | Yes |
| Temperature Range | 60->85 F |
| Control Type | Electronic |
| Cord Length | 68″ |
| Rotary Compressor | Yes |
| Outdoor Vent / Exhaust | Yes |
| Room Air Conditioner Features | Batteries Included Energy Saver Filter Reminder Function Remote Control Smart Fan Switch |
| Fan Speed Selections | 3 Cooling 3 Fan Only |
| Optional Grill | RAG13/RAG13A/RAG14E |
| Refrigerant Type | R410A |
| Plug Type | Tandem/Right Angle/LCDI |
| Thermostat Type | Electronic Digital |
| Airflow (cfm) Roomside | 280/260/240, 270/250/230 |
| Unit Type | Cool Only |
APPEARANCE
| Color Appearance | White |
| Installation | Wall Mounted |
WEIGHTS & DIMENSIONS
| Depth to Louvers | 5 |
| Overall Height | 15.625 |
| Overall Depth | 21.8125 |
| Overall Depth (Excludes Sleeve) | 19.90625 |
| Overall Width (Excludes Sleeve) | 24.8125 |
| Net Weight | 83.1 |
| Overall Width | 26 |
| Approximate Shipping Weight | 83.1 |
| Overall Height (Excludes Sleeve) | 14.875 |
POWER / RATINGS
| Volts/Hertz | 230V-208V/60Hz |
| Cooling – Watts | 940/920 |
| Cooling – Rated Cooling Amps AHAM | 4.3/4.7 |
| CEER | 10.6 |
| Voltage (MAX) | 230.000000 |
| Voltage/Hertz/Phase | 230-208/60/1 |
| Voltage (MIN) | 208 |
ACCESSORIES
| Wall Case | RAB46/47/48/26 Required At Additional Cost |
WARRANTY
| Warranty Notes | See written warranty for full details |
| Parts Warranty | Limited 2-year entire appliance |
| Labor Warranty | Limited 1-year entire appliance Limited 5-year sealed system |
CERTIFICATIONS
| Claims & Certifications | ENERGY STAR® Qualified ADA Compliant UL CUL AHAM EEV California Prop 65 |
